Product Overview

FOXBORO P0916VB is a high-performance terminal connection and signal processing module designed specifically for industrial automation control systems by Foxboro, USA. It belongs to FOXBORO’s classic I/A series control system supporting products. This product is not a power supply module, its core function is to serve as a signal transmission hub between the system and field devices. Through precise signal conditioning and stable connection performance, it achieves reliable collection and efficient transmission of industrial field data, providing data support for real-time decision-making of the control system. Its design is fully adapted to harsh industrial environments, with both installation flexibility and long-term operational stability, making it a core supporting component for system construction and upgrading in fields such as petrochemicals and intelligent manufacturing.

Specification parameters

parameter category

Specifications

Remarks

Electrical parameters

Working voltage: 220V; output frequency: 30kHz (control module attribute)/50/60Hz (adaptation attribute)

Meets industrial standard power supply requirements

transmission performance

The maximum data transmission rate is 10Mbps; Signal conditioning accuracy ± 0.5%

Support real-time industrial data exchange

environmental parameters

Working temperature: -40 ℃~+85 ℃; Protection level: IP67

Suitable for harsh environments such as high humidity and dust

Physical specifications

Connection interface: M12 connector system; Optional lengths: 5m, 10m, 15m

Standardized interfaces ensure connection reliability

Certification and Compatibility

Product certification: CE certification; Adaptation system: FOXBORO I/A series

Compliant with international industrial safety standards

Performance characteristics

-Super environmental adaptability: Using high-grade PVC insulation material and oil resistant and corrosion-resistant materials, combined with IP67 protection level, it can work stably in dust, water stains, oil stains and extreme temperature environments, meeting the strict requirements of industrial sites.

-High reliability signal transmission: Equipped with a precision signal conditioning unit, the data transmission accuracy reaches ± 0.5%, and it also has excellent anti electromagnetic interference ability, which can effectively shield the interference of complex electromagnetic environment on industrial sites, ensuring the accuracy and stability of data transmission.

-Convenient installation and maintenance: adopting standardized M12 connector design, easy insertion and removal, and firm connection; The module structure is compact, suitable for various installation scenarios, and simplifies the later maintenance process, which can effectively reduce labor and time costs.

-Wide system compatibility: Designed specifically for FOXBORO I/A series control systems, it supports multiple industrial standard protocols such as Modbus and can be easily integrated into existing control systems to meet the needs of new system construction and old system upgrades.

Working principle

FOXBORO P0916VB uses “signal conversion conditioning transmission” as its core working logic to achieve bidirectional data exchange between industrial field equipment and control systems. The specific workflow is as follows: Firstly, establish physical connections with on-site sensors, actuators, and other devices through M12 connectors to collect analog or digital signals such as temperature, pressure, and flow from the site; Subsequently, the built-in signal conditioning unit filters, amplifies, and calibrates the collected raw signal to eliminate noise interference and improve signal quality; Finally, the conditioned standard signal is transmitted to the FOXBORO I/A series control system at a maximum speed of 10Mbps, while receiving control instructions issued by the system and forwarding them to the on-site execution equipment, forming a complete control loop. During this process, the anti-interference design and stable power supply of the module ensure the continuous and reliable transmission of signals in complex industrial environments.

Precautions

1. Installation specifications: Before installation, it is necessary to confirm that the module model matches the system requirements, strictly follow the installation guidelines provided by the manufacturer, ensure that the module is firmly fixed in a dry and ventilated installation position, and avoid direct exposure to highly corrosive gases or liquids; When wiring, it is necessary to distinguish between the power end and the signal end to prevent module damage caused by reverse connection.

2. Environmental control: Although the module has the ability to work in a wide temperature range, long-term operation in extreme temperature environments (below -40 ℃ or above 85 ℃) will shorten its service life. It is recommended to equip temperature control devices when conditions permit; At the same time, avoid water ingress or complete dust coverage of the module to ensure effective IP67 protection performance.

3. Connection operation: When inserting and removing M12 connectors, vertical force should be applied to avoid interface damage caused by tilting insertion and removal; Do not plug or unplug signal cables when they are live to prevent the generation of electrical sparks that may cause safety hazards or damage to the internal circuits of the module.

4. Maintenance: Regularly (quarterly) inspect the modules and connecting cables, clean the dust and oil stains at the interfaces, and check whether the cables are damaged or aged; During maintenance, it is necessary to first cut off the power supply to the module to ensure safe operation.

5. Compatibility statement: Although it supports multiple protocols, compatibility testing should be conducted in advance when integrating with non FOXBORO I/A series systems to avoid signal transmission abnormalities caused by protocol mismatch; It is prohibited to modify module circuits or replace non original parts without authorization.

Application scenarios

Thanks to its high reliability and strong environmental adaptability, FOXBORO P0916VB is widely used in various industrial automation control fields, with core application scenarios including:

-Oil and gas industry: used for equipment signal connection in oil well extraction, oil and gas transmission pipelines, and refining plant areas, to achieve stable transmission of key parameters such as pressure and flow rate in high temperature, high pressure, and flammable and explosive environments.

-Chemical industry: Suitable for control systems of chemical reaction vessels, distillation towers, and other equipment, achieving precise collection and control command transmission of process parameters such as temperature, liquid level, and composition, ensuring stable production processes.

-General manufacturing industry: In production lines such as automobile manufacturing and mechanical processing, various sensors and actuators are connected to achieve real-time monitoring and automation control of the production process, thereby improving production efficiency.

-Power and water treatment industry: used for signal conversion of power plant generator sets and water treatment equipment, ensuring reliable transmission of parameters such as voltage and water quality in high electromagnetic interference environments, and ensuring safe operation of equipment.
